    Strenx® 700MC Plus high-strength structural steel

    Strenx® 700MC Plus is a Strenx® grade with exceptional properties for bending and mechanical cutting. It allows you to fast-forward the development of new high-performing load-bearing equipment. It has excellent formability and impact toughness for highly demanding applications, which is particularly important when operating in cold climates. Strenx® 700MC Plus meets or exceeds the requirements of EN 10149-2 grade S700MC. The product has a bendability of Ri/t equal to 1 up to 10 mm (0.393”) thickness. At a thickness above 10 mm (0.393”) the Ri/t value is still as low as 1.5.

    Download our brochure about Strenx® 700MC Plus

    pdf 549 Kb
    Strenx® 700MC Plus - A big plus for you and your customers
    Show specs in Metric Imperial

    Dimension Range

    Strenx® 700MC Plus is available as cut to length sheets in thicknesses of 3.0 - 12.0 mm, widths up to 1525 mm and lengths up to 12300 mm.

    Mechanical Properties

    Hide/Show specific columns Edit
    Select columns to display
      Thickness
      (mmin)
      Yield strength ReH 1)
      (min MPaksi)
      Tensile strength Rm
      (MPaksi)
      Elongation A5
      (min %)
      Min. inner bending radius for a 90° bend 2)
      3.0 - 10.00.118 - 0.393 700101 750 - 950109 - 138 13 1.0 x t
      10.0 - 12.00.394 - 0.472 700101 750 - 950109 - 138 13 1.5 x t
      Compare parameters

      Select one parameter to compare

      Comparison

        The mechanical properties are tested in the longitudinal direction.

        1) If ReH is not applicable then Rp0.2 is used. On thicknesses >8 mm the minimum yield strength may be 20MPa lower.

        2) For both longitudinal and transverse direction.

        Impact Properties

        Hide/Show specific columns Edit
        Select columns to display
          Product Min. impact energy for longitudinal testing,
          Charpy V 10x10 mm test specimen 1)
          Strenx® 700MC Plus 40 J / -60 °C29 ft-lbs / -76 °F
          Compare parameters

          Select one parameter to compare

          Comparison

            Product
            Strenx® 700MC Plus
            Min. impact energy for longitudinal testing,
            Charpy V 10x10 mm test specimen 1)
            40 J / -60 °C29 ft-lbs / -76 °F

            1) Impact testing in the transverse direction is available if specified at the time of the order. Minimum impact energy for transverse testing is 27 J at -40° C.

            Impact testing according to EN ISO 148-1 is performed on thicknesses ≥ 5mm. The specified minimum value corresponds to a full-size specimen.

            Chemical Composition (ladle analysis)

            Hide/Show specific columns Edit
            Select columns to display
              C
              (max %)
              Si
              (max %)
              Mn
              (max %)
              P
              (max %)
              S
              (max %)
              Altot
              (min %)
              Nb
              (max %)
              V
              (max %)
              Ti
              (max %)
              0.12 0.25 2.10 0.020 0.010 0.015 0.09 1) 0.20 1) 0.15 1)
              Compare parameters

              Select one parameter to compare

              Comparison

                1) Sum of Nb, V and Ti = max 0.22%.

                The steel is grain refined.

                Carbon Equivalent CET(CEV)

                Hide/Show specific columns Edit
                Select columns to display
                  Thickness (mmin) 3.0 - 11.40.118 - 0.452 11.5 - 12.00.453 - 0.472
                  Typ CET(CEV) 0.24 (0.38) 0.26 (0.40)
                  Compare parameters

                  Select one parameter to compare

                  Comparison

                    CET and CEV formula

                    Tolerances

                    More details are given in SSAB’s brochure Strenx® Guarantees.

                    Thickness

                    Tolerances according to Strenx® Thickness Guarantee.

                    Strenx® Guarantees offer considerably narrower thickness tolerances compared to EN 10051.

                    Length and Width

                    Width and length tolerances according to SSAB standard.

                    SSAB standard offer narrower width and length tolerances compared to EN 10051.

                    Length tolerances only apply for cut to length sheets.

                    Shape

                    Tolerances according to EN 10051. Narrower tolerances according to the SSAB standard are available on request.

                    Flatness

                    Tolerances according to Strenx® Flatness Guarantee Class A.

                    Strenx® Flatness Guarantee offer narrower tolerances compared to EN 10051.

                    Flatness guarantees only apply for cut to length sheets.

                    Surface Properties

                    According to EN 10163-2 Class A, Subclass 3.

                    Delivery Conditions

                    Thermomechanically Rolled. Strenx® 700MC Plus is available in as rolled or pickled surface condition.

                    Delivery requirements can be found in SSAB’s brochure Strenx® Guarantees or on www.ssab.com.

                    Fabrication and Other Recommendations

                    Welding, bending and machining

                    Strenx® 700MC Plus has good welding, cold forming and cutting performance.

                    Strenx® 700MC Plus is a cold forming steel not suited for heat treatments at temperatures above 580°C since the material then maylose its guaranteed properties.

                    For information concerning fabrication, see SSAB´s brochures on www.ssab.com or consult Tech Support.

                    Appropriate health and safety precautions must be taken when bending, welding, cutting, grinding or otherwise working on the products.

                    Ready to upgrade?

                    Moving up from 700 MPa to 900 MPa means you get almost 30% higher yield strength, which is the case if you upgrade from Strenx® 700MC Plus to Strenx® 900 Plus. Your upgraded equipment has higher load-bearing capacity or can be made with thinner steel for reduced weight. If you are ready to explore the opportunities with a stronger Strenx®, you’re always welcome to get in touch with our steel specialists at SSAB Tech Support or SSAB Knowledge Service Center.
