Maximize your choice of AHSS/UHSS automotive solutions: Docol® automotive steel grades include martensitic • press hardening steel • complex phase • high edge ductility • 3rd gen dual phase with high formability • and more. SSAB uses pure Swedish iron ore and advanced milling processes to make steels with extremely clean properties and highly consistent formability.
In addition to the automotive steel grades listed below, SSAB offers hundreds of Docol® variations to meet specific VDA, SAE, EN, JIS, and OEM standards. We work in close cooperation with automotive OEMs and Tier 1 suppliers to develop custom AHSS grades that give your designs a competitive edge.
We can help at each step: material selection, crash simulations, design optimization, production modeling, effective workflow planning, and tooling recommendations. Plus, you have immediate access to on-demand webinars and articles on key issues such as AHSS simulations, managing springback, and fossil-free automotive steel.
In addition to the open for sales steels listed in the “Available steel grades” tables below, SSAB is constantly developing new Docol® grades based on future needs of leading car OEMs and Tier 1 suppliers.
Here’s a list of exciting new AHSS developments. Some are “steel family extensions” — that is, grades now available in new hot-rolled or metal-coated versions. Others are all-new automotive metals, like our guaranteed hole-expansion ratio (HER) grades.
New hot-rolled grades:
Docol HR800HER-75
Docol HR800HER-100
Docol HR1500M
Docol HR1000CP
New cold-rolled grades:
Docol 1900M
Docol 1700M-EG
New metal-coated grades:
Docol CR1180CP-GI
Docol CR1180DP-GI
Docol CR1000DH-GI
Docol HR600FB-GI
Martensitic (M) steels have very high yield strength (Re) and an extremely high tensile strength (Rm). Docol® martensitic steel has good draw ability and good edge stretching properties. It is also good in welding.
Docol® Martensitic phase steel product offer:
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol 900M | Docol CR700Y900T MS | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | |
| Docol 1100M | Docol CR860Y1100T MS | UC, EG |
T: 0.50 - 2.00 mm W: Up to 1527 mmT: 0.020 - 0.0787 in W: Up to 60.12 in |
SSAB | |
| Docol 1200M | Docol CR950Y1200T MS | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | |
| Docol HR900Y1180T MS | UC |
T: 2.00 - 4.00 mm W: Up to 1440 mmT: 0.0787 - 0.157 in W: Up to 56.69 in |
SSAB | ||
| Docol 1300M | Docol CR1030Y1300T MS | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol 1400M | Docol CR1150Y1400T MS | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | |
| Docol 1500M | Docol CR1220Y1500T MS | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol HR1220Y1500T MS | UC* |
T: 2.00 - 4.00 mm W: Up to 1530 mmT: 0.0787 - 0.157 in W: Up to 60.24 in |
SSAB | ||
| Docol 1700M | Docol CR1350Y1700T MS | UC |
T: 1.00 - 2.10 mm W: Up to 1250 mmT: 0.0394 - 0.0827 in W: Up to 49.21 in |
VDA 239-100 |
*Available upon request.
Metal coated Docol® 600DH-GI and 800DH-GI are two of the steel grades now avaliable and more are on the way.
DA special heat treatment producing mainly two-phase structure makes Docol® 600DH-GI and 800DH-GI suitable where an improved formability is requested compared to conventional dual-phase steel grades with the same tensile strength level.
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol 600DH | Docol CR330Y590T-DH | GI |
T: 0.80 - 2.40 mm W: Up to 1400 mmT: 0.031 - 0.0945 in W: Up to 55.12 in |
SSAB | |
| Docol 800DH | Docol CR440Y780T DH | GI |
T: 0.80 - 2.00 mm W: Up to 1400 mmT: 0.031 - 0.0787 in W: Up to 55.12 in |
VDA 239-100 |
For Press Hardening (PHS) Steel it is the forming process which sets the final characteristics on the material. Forming at high temperatures facilitates complex structures as the martensitic microstructure is developed after press hardening. This material has a limitation in welding properties.
Docol® PHS steel product offer:
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol PHS 1500 | Docol PHS FH 1500 | UC |
T: 0.70 - 3.00 mm W: Up to 1500 mmT: 0.028 - 0.118 in W: Up to 59.06 in |
SSAB | |
| Docol PHS CR 1500 Annealed | UC |
T: 0.70 - 3.00 mm W: Up to 1500 mmT: 0.028 - 0.118 in W: Up to 59.06 in |
SSAB | ||
| Docol PHS HR 1500 | UC |
T: 2.00 - 12.00 mm W: Up to 1600 mmT: 0.0787 - 0.4724 in W: Up to 62.99 in |
SSAB | ||
| Docol PHS HR 1500+A | UC |
T: 2.00 - 12.00 mm W: Up to 1600 mmT: 0.0787 - 0.4724 in W: Up to 62.99 in |
SSAB | ||
| Docol PHS 1800 | Docol PHS FH 1800 | UC |
T: 0.70 - 3.00 mm W: Up to 1500 mmT: 0.028 - 0.118 in W: Up to 59.06 in |
SSAB | |
| Docol PHS CR 1800 Annealed | UC |
T: 0.70 - 3.00 mm W: Up to 1500 mmT: 0.028 - 0.118 in W: Up to 59.06 in |
SSAB | ||
| Docol PHS 2000 | Docol PHS FH 2000 | UC |
T: 1.00 - 2.10 mm W: Up to 1515 mmT: 0.0394 - 0.0827 in W: Up to 59.65 in |
SSAB | |
| Docol PHS CR 2000 Annealed | UC |
T: 1.00 - 2.10 mm W: Up to 1515 mmT: 0.0394 - 0.0827 in W: Up to 59.65 in |
SSAB | ||
| Docol PHS HR 2000 | UC |
T: 2.00 - 4.00 mm W: Up to 1600 mmT: 0.0787 - 0.157 in W: Up to 62.99 in |
SSAB | ||
| Docol PHS HR 2000+A | UC |
T: 2.00 - 4.00 mm W: Up to 1600 mmT: 0.0787 - 0.157 in W: Up to 62.99 in |
SSAB |
Complex Phase (CP) steels have higher yield strength and lower work hardening effect, compared to DP steels for same strength level. The CP steels have good fatigue properties when it comes to low cycle fatigue. Compared to DP, the CP steels offer better flanging and ISO hole expansion performance and these automotive metals are suitable for applications where high strength, good bendability and stretch-flange ability is required.
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol 600CP | Docol CR350Y600T-CP | GI, GA, ZA |
T: 0.70 - 2.50 mm W: Up to 1520 mmT: 0.028 - 0.0984 in W: Up to 59.84 in |
SSAB | |
| HCT600C | - |
T: 0.70 - 2.50 mm W: Up to 1520 mmT: 0.028 - 0.0984 in W: Up to 59.84 in |
EN 10346 |
-
|
|
| Docol 800CP | Docol CR570Y780T CP | UC, GI, GA*, ZA* |
T: 0.80 - 2.50 mm W: Up to 1527 mmT: 0.031 - 0.0984 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol HR660Y760T CP | UC, GI |
T: 2.00 - 4.00 mm W: Up to 1500 mmT: 0.0787 - 0.157 in W: Up to 59.06 in |
VDA 239-100 | ||
| Docol HR800HER 75 | UC, GI |
T: 2.00 - 4.00 mm W: Up to 1500 mmT: 0.0787 - 0.157 in W: Up to 59.06 in |
SSAB | ||
| Docol HR800HER 100 | UC |
T: 2.00 - 4.00 mm W: Up to 1500 mmT: 0.0787 - 0.157 in W: Up to 59.06 in |
SSAB | ||
| Docol Roll 800 | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| HCT780C | - |
T: 0.80 - 2.10 mm W: Up to 1527 mmT: 0.031 - 0.0827 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT780C | - |
T: 0.80 - 2.50 mm W: Up to 1460 mmT: 0.031 - 0.0984 in W: Up to 57.48 in |
EN 10346 |
-
|
|
| Docol 1000CP | Docol CR780Y980T CP | UC, EG, GI |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol Roll 1000 | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| Docol Roll 1000HY | UC, EG |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| Docol HR720Y950T CP | UC* |
T: 3.00 - 4.00 mm W: Up to 1510 mmT: 0.118 - 0.157 in W: Up to 59.45 in |
SSAB | ||
| HCT980C | - |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT980C | - |
T: 1.00 - 2.00 mm W: Up to 1250 mmT: 0.0394 - 0.0787 in W: Up to 49.21 in |
EN 10346 |
-
|
|
| Docol 1200CP | Docol CR900Y1180T CP | UC, EG, GI* |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 |
*Available upon request.
For Dual Phase (DP) steels there is a big difference in yield and tensile strength in un-deformed areas. The work hardening in forming is very strong. DP steels have good formability compared to its strength but are limited in hole expansion. With its lean composition these steels are easy to weld but sensitive to heat treatment (> 200 °C).
Docol® dual phase steel product offer:
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol 500DP | Docol CR290Y490T DP | UC, GI, GA*, ZA |
T: 0.50 - 3.00 mm W: Up to 1527 mmT: 0.020 - 0.118 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol CR230Y500T DL | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| Docol CR290Y500T DP | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| HCT490X | - |
T: 0.50 - 2.00 mm W: Up to 1527 mmT: 0.020 - 0.0787 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT490X | - |
T: 0.70 - 3.00 mm W: Up to 1520 mmT: 0.028 - 0.118 in W: Up to 59.84 in |
EN 10346 |
-
|
|
| Docol 600DP | Docol CR330Y590T DP | UC, GI, GA, ZA |
T: 0.50 - 3.00 mm W: Up to 1527 mmT: 0.020 - 0.118 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol CR280Y600T DL | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| Docol CR350Y600T DP | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| HCT590X | - |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT590X | - |
T: 0.65 - 3.00 mm W: Up to 1520 mmT: 0.026 - 0.118 in W: Up to 59.84 in |
EN 10346 |
-
|
|
| Docol 800DP | Docol CR440Y780T DP | UC, GI, GA, ZA* |
T: 0.50 - 2.50 mm W: Up to 1527 mmT: 0.020 - 0.0984 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol CR450Y780T DP | UC |
T: 0.80 - 2.00 mm W: Up to 1527 mmT: 0.031 - 0.0787 in W: Up to 60.12 in |
SSAB | ||
| Docol CR390Y800T DL | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| Docol CR500Y800T DP | UC |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
SSAB | ||
| Docol 800DPX | GI, GA* |
T: 0.80 - 2.00 mm W: Up to 1527 mmT: 0.031 - 0.0787 in W: Up to 60.12 in |
SSAB | ||
| HCT780X | - |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT780X | - |
T: 0.80 - 2.50 mm W: Up to 1460 mmT: 0.031 - 0.0984 in W: Up to 57.48 in |
EN 10346 |
-
|
|
| Docol 1000DP | Docol CR590Y980T DP | UC, EG, GI, GA, ZA |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol CR700Y980T DP | UC, EG, GI, GA*, ZA* |
T: 0.70 - 2.10 mm W: Up to 1527 mmT: 0.028 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 | ||
| Docol CR700Y980T DP LCE | UC, EG, GI, GA*, ZA* |
T: 0.50 - 2.10 mm W: Up to 1511 mmT: 0.020 - 0.0827 in W: Up to 59.49 in |
SSAB | ||
| Docol CR700Y1000T DP | UC, EG |
T: 0.50 - 2.00 mm W: Up to 1527 mmT: 0.020 - 0.0787 in W: Up to 60.12 in |
SSAB | ||
| Docol 1000DPX | GI, GA* |
T: 1.00 - 2.00 mm W: Up to 1320 mmT: 0.0394 - 0.0787 in W: Up to 51.97 in |
SSAB | ||
| HCT980X | - |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT980XG | - |
T: 0.70 - 2.10 mm W: Up to 1527 mmT: 0.028 - 0.0827 in W: Up to 60.12 in |
EN 10338 |
-
|
|
| HCT980X | - |
T: 0.95 - 2.00 mm W: Up to 1250 mmT: 0.037 - 0.0787 in W: Up to 49.21 in |
EN 10346 |
-
|
|
| HCT980XG | - |
T: 0.95 - 2.00 mm W: Up to 1250 mmT: 0.037 - 0.0787 in W: Up to 49.21 in |
EN 10346 |
-
|
*Available upon request.
Docol® HE is a new range of hot rolled advanced high strength steel (AHSS) with improved edge ductility for automotive manufacturers facing technical challenges in production.
Docol® High Edge Ductility steel product offer:
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol 355HE | Docol HR355Y430T HE | UC |
T: 2.00 - 7.00 mm W: Up to 1600 mmT: 0.0787 - 0.276 in W: Up to 62.99 in |
SSAB | |
| Docol 420HE | Docol HR420Y480T HE | UC |
T: 2.00 - 7.00 mm W: Up to 1600 mmT: 0.0787 - 0.276 in W: Up to 62.99 in |
SSAB | |
| Docol 460HE | Docol HR460Y520T HE | UC |
T: 2.00 - 7.00 mm W: Up to 1600 mmT: 0.0787 - 0.276 in W: Up to 62.99 in |
SSAB | |
| Docol 500HE | Docol HR500Y550T HE | UC |
T: 2.00 - 7.00 mm W: Up to 1600 mmT: 0.0787 - 0.276 in W: Up to 62.99 in |
SSAB | |
| Docol 550HE | Docol HR550Y600T HE | UC |
T: 2.00 - 7.00 mm W: Up to 1600 mmT: 0.0787 - 0.276 in W: Up to 62.99 in |
SSAB |
High Strength Low Alloy (HSLA) steels have a typically small difference between yield strength and tensile strength (<100 MPa). They, therefore, offer excellent bendability. With little pearlite and no other hard phases they also have better fine blanking properties compared to DP steels and due to lean composition they are very easy to weld.
Docol® High Strength Low Alloy steel product offer:
| Product Family | Product Name | Coating | Dimensions | Standards | Datasheet |
|---|---|---|---|---|---|
| Docol 420LA | Docol CR420LA | GI, GA*, ZA* |
T: 0.80 - 2.00 mm W: Up to 1500 mmT: 0.031 - 0.0787 in W: Up to 59.06 in |
VDA 239-100 | |
| Docol HR420LA | UC, GI* |
T: 2.00 - 6.00 mm W: Up to 1600 mmT: 0.0787 - 0.236 in W: Up to 62.99 in |
VDA 239-100 | ||
| HC420LA | - |
T: 0.50 - 3.00 mm W: Up to 1527 mmT: 0.020 - 0.118 in W: Up to 60.12 in |
EN 10268 |
-
|
|
| HX420LAD | - |
T: 0.50 - 2.50 mm W: Up to 1500 mmT: 0.020 - 0.0984 in W: Up to 59.06 in |
EN 10346 |
-
|
|
| Docol 460LA | Docol CR460LA | UC, GI, GA*, ZA* |
T: 0.50 - 2.10 mm W: Up to 1527 mmT: 0.020 - 0.0827 in W: Up to 60.12 in |
VDA 239-100 | |
| Docol HR460LA | UC |
T: 2.00 - 6.00 mm W: Up to 1600 mmT: 0.0787 - 0.236 in W: Up to 62.99 in |
VDA 239-100 | ||
| HC460LA | - |
T: 0.50 - 2.00 mm W: Up to 1527 mmT: 0.020 - 0.0787 in W: Up to 60.12 in |
EN 10268 |
-
|
|
| HX460LAD | - |
T: 0.80 - 2.00 mm W: Up to 1500 mmT: 0.031 - 0.0787 in W: Up to 59.06 in |
EN 10346 |
-
|
|
| Docol 500LA | Docol HR500LA | UC |
T: 2.00 - 6.00 mm W: Up to 1600 mmT: 0.0787 - 0.236 in W: Up to 62.99 in |
VDA 239-100 | |
| HC500LA | - |
T: 0.50 - 2.00 mm W: Up to 1527 mmT: 0.020 - 0.0787 in W: Up to 60.12 in |
EN 10268 |
-
|
|
| HX500LAD | - |
T: 0.80 - 2.00 mm W: Up to 1410 mmT: 0.031 - 0.0787 in W: Up to 55.51 in |
EN 10346 |
-
|
|
| Docol 550LA | Docol HR550LA | UC, GI* |
T: 2.00 - 6.00 mm W: Up to 1600 mmT: 0.0787 - 0.236 in W: Up to 62.99 in |
VDA 239-100 | |
| Docol 600LA | Docol HR600LA | UC |
T: 2.00 - 6.00 mm W: Up to 1600 mmT: 0.0787 - 0.236 in W: Up to 62.99 in |
SSAB | |
| Docol 650LA | Docol HR650LA | UC |
T: 2.000 - 6.00 mm W: Up to 1600 mmT: 0.07874 - 0.236 in W: Up to 62.99 in |
SSAB | |
| Docol 700LA | Docol HR700LA | UC, EG, GI* |
T: 2.00 - 6.00 mm W: Up to 1600 mmT: 0.0787 - 0.236 in W: Up to 62.99 in |
VDA 239-100 | |
| Docol S600MC | Docol S600MC D | UC |
T: 2.00 - 10.00 mm W: Up to 1600 mmT: 0.079 - 0.393 in W: Up to 62.99 in |
EN 10149-2 | |
| Docol S600MC E | UC |
T: 2.00 - 10.00 mm W: Up to 1600 mmT: 0.079 - 0.393 in W: Up to 62.99 in |
EN 10149-2 | ||
| Docol S650MC | Docol S650MC D | UC |
T: 2.00 - 10.00 mm W: Up to 1600 mmT: 0.079 - 0.393 in W: Up to 62.99 in |
EN 10149-2 | |
| Docol S650MC E | UC |
T: 2.00 - 10.00 mm W: Up to 1600 mmT: 0.079 - 0.393 in W: Up to 62.99 in |
EN 10149-2 | ||
| Docol S700MC | Docol S700MC D | UC |
T: 2.00 - 10.00 mm W: Up to 1600 mmT: 0.079 - 0.393 in W: Up to 62.99 in |
EN 10149-2 | |
| Docol S700MC E | UC |
T: 2.00 - 10.00 mm W: Up to 1600 mmT: 0.079 - 0.393 in W: Up to 62.99 in |
EN 10149-2 | ||
| Docol S900MC | Docol S900MC | - | T: 3.00 - 10.00 mmT: 0.118 - 0.3937 in | EN 10149-2 | |
| Docol S960MC | Docol S960MC | - | T: 3.00 - 10.00 mmT: 0.118 - 0.3937 in | EN 10149-2 | |
| Docol HR100XF | Docol HR100XF | UC | T: 2.00 - 10.00 mmT: 0.079 - 0.393 in | - | |
| Docol HR110XF | Docol HR110XF | UC | T: 2.00 - 10.00 mmT: 0.079 - 0.393 in | - |
